Peplink Add-ons and Accessories

With 4 cellular channels, the Puma 401 is a powerhouse, capable of providing you high bandwidth and solid reliability even under heavy usage. Equipped with high gain LNA, the GPS receiver has improved location tracking.

• 4x Cellular
• 1x GPS
• 7dBi Gain
• 5G Ready

Each number and letter after the series name, has its own meaning and purpose. Here’s what it stands for:

  ⚬ The first number represents the number of LTE element

  ⚬ The second represents the number of Wi-Fi element

  ⚬ The third represents the number of GPS element

The next letter in the SKU numbering represents the RF connector type, there are 3 options for this: S-SMA male; Q- QMA male; N- N-type male.

The letter following this will simply represent the colour of the model: B- Black; W- White.

The final number will represent RF cable length ft: 1- 1ft/0.3 meters; 6-6.5ft/2 meters.

There are three length option of Puma Antenna:

⚬ Option 1 – 1ft/0.3m) For any short-range deployments between the router and the antenna

⚬ Option 2 – 6.5ft/2m) For middle range deployments.

⚬ Option 3 – 16ft/4.8m) For long range deployments,this will require a short pigtail (Puma-xxx-Q-x-1) plus an extension cable (EXC-xQ-15).

With 2 cellular channels, 2 Wi-Fi channels, and a high gain LNA GPS, the Puma 221 is a versatile all-in-one cellular antenna solution. It has 2×2 MIMO and dual-band Wi-Fi for high bandwidth and solid reliability.

• 2x Cellular
• 2x Wi-Fi
• 1x GPS
• 7dBi Gain
• 5G Ready

Each number and letter after the series name, has its own meaning and purpose. Here’s what it stands for:

  ⚬ The first number represents the number of LTE element

  ⚬ The second represents the number of Wi-Fi element

  ⚬ The third represents the number of GPS element

The next letter in the SKU numbering represents the RF connector type, there are 3 options for this: S-SMA male; Q- QMA male; N- N-type male.

The letter following this will simply represent the colour of the model: B- Black; W- White.

The final number will represent RF cable length ft: 1- 1ft/0.3 meters; 6-6.5ft/2 meters.

There are three length option of Puma Antenna:

⚬ Option 1 – 1ft/0.3m) For any short-range deployments between the router and the antenna

⚬ Option 2 – 6.5ft/2m) For middle range deployments.

⚬ Option 3 – 16ft/4.8m) For long range deployments,this will require a short pigtail (Puma-xxx-Q-x-1) plus an extension cable (EXC-xQ-15).

The Puma 020 is a low-cost, dual-band Wi-Fi antenna built for mobile applications. It comes with 2×2 MIMO that provides you with a high bandwidth and solid reliability despite its price.

• 2x Wi-Fi
• 7dBi Gain

Each number and letter after the series name, has its own meaning and purpose. Here’s what it stands for:

  ⚬ The first number represents the number of LTE element

  ⚬ The second represents the number of Wi-Fi element

  ⚬ The third represents the number of GPS element

The next letter in the SKU numbering represents the RF connector type, there are 3 options for this: S-SMA male; Q- QMA male; N- N-type male.

The letter following this will simply represent the colour of the model: B- Black; W- White.

The final number will represent RF cable length ft: 1- 1ft/0.3 meters; 6-6.5ft/2 meters.

There are three length option of Puma Antenna:

⚬ Option 1 – 1ft/0.3m) For any short-range deployments between the router and the antenna

⚬ Option 2 – 6.5ft/2m) For middle range deployments.

⚬ Option 3 – 16ft/4.8m) For long range deployments,this will require a short pigtail (Puma-xxx-Q-x-1) plus an extension cable (EXC-xQ-15)

Wideband 690-2700 MHz LTE Antenna. # of antennas Required for a dual-cellular router: 1;

for quad-cellular: 2

• 4x LTE connectors
• 1 GPS Connector
• 4dBi Gain

ANT-100-LTE4-G (SMA)

ANT-100-LTE4 (N-Type)

1x 2-in-1 High Gain Outdoor Antenna

Outdoor IP67 Omni Antenna

• 2x MIMO for 1x LTE/3G Antenna
• 1x GPS Antenna
• 3m cable length, SMA (M)

1x 3-in-1 High Gain Outdoor Antenna

Outdoor IP67 Omni Antenna

• 2x MIMO for 1x LTE/3G Antenna
• 1x GPS Antenna
• 1x Wi-Fi Antenna
• 3m cable length, SMA (M)

Super Wideband 690-3800 MHz LTE Antenna, 5G ready

• 2x SMA LTE connectors
• 1 GPS Connector
• 6dBi Gain

Wideband 698-2700 MHz LTE Antenna

• 2x SMA LTE connectors
• 4dBi gain

Wideband 698-2700 MHz High Gain LTE Antenna

• 2x SMA connectors
• 9dBi gain

Wideband 690-2700 MHz LTE Antenna

Requires 1 unit per 3G modem, 2 units per LTE modem

• 1x 4dBi Outdoor Cellular Omni Antenna for 1x 3G Modem (N-Female)
• 698-960/1710-2700 MHz
• Requires two units per LTE radio

Magnetic Base Wi-Fi Indoor Omni Antenna (RP-SMA)

• 2.4Ghz
• 5dBi Gain

Indoor Wi-Fi Omni Antenna (RP-SMA)

• 2.4Ghz
• 5dBi Gain

Dual-Band Indoor Wi-Fi Omni Antenna in White (RP-SMA)

• 5GHz & 5dBi
• 2.4GHz & 2.5dBi

Dual-Band Indoor Wi-Fi Omni Antenna in Black (RP-SMA)

• 5GHz & 5dBi
• 2.4GHz & 2.5dBi

Fiberglass Outdoor Wi-Fi Omni Antenna (N-Male)

• 2.4Ghz
• 8dBi Gain

Fiberglass Outdoor Wi-Fi Omni Antenna (N-Male)

• 5.8Ghz
• 8dBi Gain

For 802.11b/g/n 300Mbps Wi-Fi Compatible with: AP Pro and AP Pro 300M

• N-Male


For 802.11a/n 300Mbps Wi-Fi deployments.

Compatible with: AP Pro 300M

• N-Male


Outdoor Wi-Fi Antenna Kit

For 802.11a/n and b/g/n 600Mbps Wi-Fi deployments

Compatible with: AP Pro Duo

• N-Male


Indoor Cellular Magnetic Omni Antenna

Requires 1 unit per 3G modem, 2 units per LTE modem

• 3dBi Gain
• SMA Connectors

Indoor Cellular Antenna. (704-960MHz/1575MHz:1dBi; 1710-2170MHz: 3dBi; 2300-2690MHz: 2dBi)

• Peak 3dBi Gain
• SMA Connectors

Indoor Magnetic 3G Antenna

• Peak 3dBi Gain
• SMA Connectors

Indoor 3G Antenna

• 2dBi Gain
• SMA Connectors

Magnetic GPS Antenna

• SMA Connectors
